DRUG-seq: A Validated Method For Drug Discovery

DRUG-seq is a novel high-throughput, cost-effective RNA-seq method for drug discovery (Ye et al., 2018; Li et al., 2022). Researchers have used DRUG-seq and similar techniques for compound screening applications in many disease areas. Like all novel methods, high-throughput sequencing techniques require extensive validation before use at scale.

In this article, we focus on how Ye et al. (2018) validated DRUG-seq and we suggest another alternative to this technique for high-throughput, industrial-scale drug discovery.

Validation of the method

Ye et al. (2018) used different experimental techniques, as well as comparisons to known compound screening data sets to ensure DRUG-seq was accurate, sensitive and appropriate for drug discovery.

Firstly, researchers tested the sensitivity of DRUG-seq at 2 and 13 million reads per well compared to the standard 42 million reads per sample. Similar numbers of expressed and differentially expressed genes were detected, even at shallow read depths, when compared to standard RNA-seq read depths.

Validation of DRUG-seq screening results

Next, the researchers performed proof-of-concept experiments. They used DRUG-seq to screen 433 compounds with primarily known targets, across eight doses in an osteosarcoma cell line. The screen revealed that compounds could be grouped into functional clusters based on the transcriptional profile of cells after drug treatment.

Ye et al. (2018) identified four functional clusters relating to signaling, translation, epigenetics and cell cycle (Fig. 1).



blog

Figure 1. t-distributed Stochastic Neighbor Embedding (t-SNE) clustering using 4289 dysregulated genes following compound treatment at 10 μM. Colors group compounds with common mechanisms of action. Each compound and its target are labeled. Figure is taken from Ye et al. (2018) Nature Communications.

In the translation cluster, two compounds that targeted key components of the translation machinery clustered closely with a compound with unknown targets. This suggested that the compound with unknown targets likely shared a similar mechanism of action.

In the epigenetic cluster, related but distinct compounds were grouped together. Unexpectedly, these compounds had different dose-dependent effects on gene expression.

Together, these results highlight that DRUG-seq can be used to infer mechanisms of action, potential targets of novel compounds, and their dose dependencies.

As further validation of their technique, Ye et al. (2018) compared their results to the Connectivity Map database; a fixed panel of about 1000 landmark genes following compound treatment (Subramanian et al., 2017). They confirmed that 52 of the 433 compounds causing gene expression changes were also present in this independent data set.

Validation for CRISPR knockout cells

Many drug discovery applications now begin with CRISPR/CAS9 gene editing, especially when target-specific compounds are unavailable. Therefore, Ye et al. (2018) compared the transcriptional effects of CRISPR knockout and compound treatment. They did this for a key component of the translation machinery called RPL6.

DRUG-seq found that CRISPR reduced RPL6 mRNA levels but drug treatment did not. Furthermore, CRISPR- and compound-treated cells had only a partial overlap in differentially expressed genes.

This was possibly due to the different mechanisms used by CRISPR or compound treatment to inhibit RPL6. The different genes detected also indicated possible off-target effects for each method. Therefore, DRUG-seq is a powerful tool for whole transcriptome readouts in a high-throughput compound or CRISPR screening environment.

Other high-throughput transcriptomic methods for drug discovery

Other technologies such as Bulk RNA Barcoding and sequencing (BRB-seq) are also extremely well suited to high-throughput transcriptomic screening of CRISPR- or compound libraries in the industrial setting. Of note, BRB-seq has been extensively optimized and validated to provide sensitive, accurate data even for low-quality RNA (Alpern et al., 2018).

Furthermore, Alithea Genomics has extensively validated BRB-seq to give the best quality data for different cell types, such as blood cells, with the inclusion of a proprietary globin blocker.

Thanks to these technologies, researchers and the pharmaceutical industry can now screen and infer the likely targets, potential mechanisms of action, and subtle dose dependencies for thousands of compounds with unparalleled accuracy.

Please contact us at info@alitheagenomics.com to find out more about how BRB-seq could help in your high-throughput drug discovery study.



References

  • Alpern, D., Gardeux, V., Russeil, J., Mangeat, B., Meireles-Filho, A.C., Breysse, R., Hacker, D. and Deplancke, B., 2019. BRB-seq: ultra-affordable high-throughput transcriptomics enabled by bulk RNA barcoding and sequencing. Genome biology, 20(1), pp.1-15.
  • Li, J., Ho, D.J., Henault, M., Yang, C., Neri, M., Ge, R., Renner, S., Mansur, L., Lindeman, A., Kelly, B. and Tumkaya, T., 2022. DRUG-seq Provides Unbiased Biological Activity Readouts for Neuroscience Drug Discovery. ACS Chemical Biology. 17(6), pp.1401-1414.
  • Subramanian, A., Narayan, R., Corsello, S.M., Peck, D.D., Natoli, T.E., Lu, X., Gould, J., Davis, J.F., Tubelli, A.A., Asiedu, J.K. and Lahr, D.L., 2017. A next generation connectivity map: L1000 platform and the first 1,000,000 profiles. Cell, 171(6), pp.1437-1452.
  • Ye, C., Ho, D.J., Neri, M., Yang, C., Kulkarni, T., Randhawa, R., Henault, M., Mostacci, N., Farmer, P., Renner, S. and Ihry, R., 2018. DRUG-seq for miniaturized high-throughput transcriptome profiling in drug discovery. Nature communications, 9(1), pp.1-9.
